SKOOR Object Tree

This offers a tree view of all the available SKOOR objects, with the possibility to search directly

In the following example, the city Bern was searched:

Object State & Value

Clicking on a specific object in the tree view will show its State history and parameter values:

In the following example, a new Group, device, and job will be added to summarize the functionalities accessible from the Dashboard.

Click Add group from the context menu of a specific group

Enter the values of the Parameters and the custom properties (if any exists)
Then trigger Ok on the lower right part of the dialog

The new group has been added successfully

Using Add device to add Weather Aarau

Using Add job to add weather data

For more details about the SKOOR Engine Jobs check Jobs on SKOOR Engine

The List of created items looks as follows:

Now the nested Job can be started by selecting start job from the context menu of the Data job.

The final outcome of this job can be seen by clicking on the Job’s name:

New SLOs (Service Level Objects) and SLCs (Service Level Controllers) can be created/maintained using the context menu.

It is possible to edit a group, device or a job directly from the Dashboard

Click on the next to the name of a component to edit in the tree view and select the edit button

A dialog will pop up with the edit view from SKOOR Engine to the selected component, and this would respectively look like this

Click on the next to the name of a component to delete in the tree view and select the delete

Control the propagation of the delete action using the flag Delete object and all sub objects

Confirm the deletion by clicking Delete Object
